Axis ART 999 Front Wing Hydrofoil Front Wing — full deck view

Photo: AXIS Foils

Axis
Axis · Hydrofoil Front Wing

Axis ART 999 Front Wing Review

Average price$683Range $683–$683 across 1 retailersSee sources

The AXIS ART 999 is the wing that made high-aspect foiling accessible. A 999 mm span, 9.9 aspect ratio carbon front wing with squared-off tips and only 1010 cm² of projected area, it delivers glide and pump normally reserved for race foils without the punishing low-end most high-aspect wings demand.

View on AXIS Foils
Quick specs
Span
999 mm
Aspect ratio
9.9
Projected area
1010 cm²
Series
ART — AXIS Research Team
Material
Carbon
Fuselage
AXIS thin Black fuselage

AXIS name their front wings from span, so the ART 999 is 999 mm wide. What sets it apart is the aspect ratio of 9.9 against a projected area of only 1010 cm² — numbers that on paper read like a kite race foil rather than a surf wing.

AXIS describe the ART series as "a reduced chord, high-aspect wing" with "good speed and glide capabilities, with an effortless pump and a very low stall speed", achieved without sacrificing the ability to turn predictably.

Pros & cons
  • Low-end lift far beyond what 1010 cm² suggests
  • Gradual, controlled lift rather than the usual choppy high-aspect feel
  • Works across prone, SUP, wing, downwind and boat tow
  • Squared tips with downward twist smooth out stall speed
  • Wants a board that planes and makes speed early
  • Turning is less playful than a low-aspect surf wing
  • Best results need an AXIS Power Carbon mast and Progressive or Skinny rear

How it surfs

Foiling Magazine tested a pre-release unit and singled out the plan shape: rather than tapering the tips to a point, AXIS carry width and area all the way to squared-off tips, adding a subtle downward twist there to smooth the low-end stall. Their verdict was that "the ART999 rides nothing like you'd expect it to. Go in with high aspect presumptions, and you're going way off the mark."

Their most surprising result came from SUP foiling, where a wing this size and aspect ratio should have failed in small swell. Instead they reported "a level of speed, carving and pumpability we didn't think we'd ever get on a board that size", with the effect amplified further on prone. Behind a boat it sat happily on the second wake and pumped indefinitely.

Volume & sizing chart

Use the chart below as a starting point. Add half a litre if you are less experienced, subtract half a litre for a looser feel.

SizeVolumeRider weightBest for
ART 9991010 cm²All-round prone / wingIntermediate+
ART v2 1099LargerLighter wind, heavier ridersIntermediate
ART v2 819SmallerHigher speed, lighter ridersAdvanced

How it compares

BoardBest atWave rangeAggregate score
Axis ART 999High-aspect glide and pump1010 cm²9.0
Unifoil Progression 170Prone surf all-rounder1200 cm² class9.4
Armstrong HA1125High-aspect prone and wing1125 cm²9.4
Code S-850Compact high-aspect850 cm² class9.4

Verdict

The wing that proved high-aspect does not have to mean difficult. If you want glide and pump without giving up usable low-end, the ART 999 remains one of the reference points.

Estimated score: 9.0 / 10
Estimated from 2 independent sources — see full list below.

What reviewers around the web are saying

Surfex does not test gear directly. Below are independent retailer and editorial sources. When a source publishes a numeric score, it is normalized to a five-point scale; otherwise the source is listed without a score.

Estimated score
9.0/ 10
9.0
2 sources, none scored
SourceScoreSummary
Foiling Magazine — gear testNo numeric score"For a 1010cm2 wing, the low-end performance will far surpass your expectations, not only with regards early lift, but also how gradual and controlled this is."
AXIS Foils — product pageNo numeric score"They feature good speed and glide capabilities, with an effortless pump and a very low stall speed. The ART achieves all this without sacrificing its ability to turn easily and predictably."

Where to buy & average price

Listed prices come from verified retailer pages. The average price below is an unweighted mean of verified retailer prices — converted to USD (≈) when retailers list in different currencies. Click any retailer to verify the native-currency price.

Average price
$683
$683–$683 · 1 retailers
RetailerPricevs. average
AXIS Foils$683Visit

Frequently asked questions

What does ART stand for on AXIS foils?+

AXIS Research Team. It is AXIS's high-aspect, reduced-chord front wing series, sitting above their Surf Performance and Broad Spectrum Carve lines for glide and pump.

What are the AXIS ART 999 specifications?+

999 mm span, 9.9 aspect ratio and 1010 cm² projected area, in carbon, mounting to the AXIS thin Black fuselage.

Is the ART 999 suitable for prone surf foiling?+

Yes. AXIS list prone among its recommended uses, and Foiling Magazine found the low-end lift transferred to prone in an amplified form compared with SUP.

What mast and rear wing pair with the ART 999?+

AXIS recommend a Power Carbon or Power Carbon High Modulus mast with a Progressive or Skinny rear wing.

How much does the AXIS ART 999 cost?+

AXIS list it at $683 USD on their own store. Screws are sold separately.
